KEYSTONE KTLD-85-UV-P2300-55-VDIM-LT2 85W Programmable 0-10V Dimmable LED Driver

Get precise, reliable LED lighting control with the KTLD-85-UV-P2300-55-VDIM-LT2, an 85W programmable LED driver designed for professional and commercial lighting applications.

With a 120–277VAC universal input and programmable 230–2300mA output current range, this driver gives installers and lighting professionals the flexibility to configure output for compatible LED fixtures. Output current can be programmed in precise 1mA increments for fine-tuned system performance.

Smooth 0-10V Dimming

Nobody wants expensive LED lighting that dims like a haunted basement.

The KTLD-85-UV-P2300-55-VDIM-LT2 provides flicker-free 0-10V dimming with true 1% dimming across the full output current range. It is also ANSI C137.1 compliant and supports multiple programmable dimming options.

Key Features

• 85W maximum power
• 120–277VAC ±10% input voltage
• 50/60Hz input frequency
• 230–2300mA programmable output current range
• 1mA output-current programming increments
• 2.3mA minimum output current
• 0-10V dimming
• True 1% dimming
• ANSI C137.1 compliant
• Flicker-free performance
• Linear metal housing
• 10-year limited warranty

Advanced Programming Features

Configure the driver for the requirements of your LED lighting system with programmable features including:

• Minimum dimming level from 1–10% in 0.5% increments
• Linear, Logarithmic or Square dimming curves
• Dim-to-Off Enable/Disable
• Luminous Decay Compensation Enable/Disable
• End-of-Life Feedback Enable/Disable
• Thermal Foldback Temperature Selection

Built for Professional LED Lighting

The linear metal enclosure makes this programmable LED driver well suited for integration into compatible commercial and architectural LED fixtures.

Ideal applications include commercial lighting, architectural lighting, linear LED fixtures, office lighting, retail lighting, institutional lighting and LED retrofit applications.

Specifications

Model: KTLD-85-UV-P2300-55-VDIM-LT2
Maximum Power: 85W
Input Voltage: 120–277VAC ±10%
Input Frequency: 50/60Hz
Programmable Output Current: 230–2300mA
Minimum Output Current: 2.3mA
Dimming: 0-10V
Minimum Dimming: 1%
Housing: Linear Metal Casing
Warranty: 10-Year Limited Warranty
